San Francisco : Architect and Engineer, Inc · leaf 412
PRELIMINARY ARCHITECTS DRAWING OF LIFT TYPE BRIDGE. OVERSACRAMENTO RIVER AT M STREET, SACRAMENTO. CALIFORNIA protected by curbs which allow 13 feet for factory structure can be secured by build-railway traffic. Two lanes of highway ing entirely new piers at new locations,traffic in each direction… … TYlICAL CROSS SECTION OF M STREET BRIDGE OVER SACRAMENTORIVER. SACRAMENTO. CALIFORNIA THE ARCHITECT AND ENGINEER ^ 52 ► MARCH, NINETEEN THIRTY-FOUR fenders, for river traffic, of 1 70 feet and avertical clearance, with span lifted, of 100feet above high water. The grade of thebridge will be…
