6), d and likewise Fcan be found. As shown by equation (7) F is 25,-400 lbs and d is 18.08 in., and the scale of thedrawing is established. According to (8) the dis-tance between bars is 10.10 in. Taking momentsabout the right-hand bar in (9) shows that theforce in the left-hand bar is 20,800 lbs,… … Gift SufascriptinnFor Christmas 1354 As a service to its readers GIFT SUBSCRIP-TIONS to ARCHITECT & ENGINEER maga-zine are available for this years Christinas giving. REGULAR SUBSCRIPTION Rate will apply: United States and Pan America$3.00 a year; two years $5.00 Foreign Countries $5.00 a year…
