n pipe to a pointnear where it was to be used. This pipe terminated in a 6-inch tee, the twostraight ends of which were bushed to 3 inches. From each of these led inorder, a nipple, tee. nipple and ellxiw, and from the tees and elbows, four 2-inch outlets, each equipped with a gate valve. From… … 74 The Architect and Engineer of the four jetting- pipes. Tlic jetting pipes were arranged in pairs and sofastened, a pair being placed on each side of the pile. The pipes extendingslightly below the lower extremity of the pile terminated in a nozzle in theend of which was a j4-inch opening. The…
