Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings (1895)

Freitag, Joseph Kendall · New York, J. Wiley & sons; [etc., etc.] · leaf 122

An illustration from Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings, 1895, leaf 122 — 1 Fig. 54- … Fig. 56. 104 ARCHITECTURAL ENGINEERING. spandrel-walls is supported directly by the main spandrel-beams, as indicated in the previous figures. The ornamental terra-cotta work, however, can seldombe supported directly by the spandrel-beams, and a systemof anchors must be resorted to, to properly tie…

Building, Iron and steel
