Smith, T. Roger (Thomas Roger), 1830-1903 · New York : Scribner and Welford · leaf 39
g,and vaults went on increasing in complexity and elaboration tillthe Tudor period, when fan-vaulting was employed. Our illus-trations show some of the steps in the development of Gothicvaults referred to in Chapter V. of the text. No. 1 represents awaggon-head vault with an intersecting vault…
Architecture, Gothic · Architecture, Renaissance
