e headles, and of applying the cords by which theseheadles are to be worked ; these plans are generally called the 102 THE ART OP WEAVING. DRAUGHT AND CORDING. Plans of this description may be considered as horizontal sectionsof a loom, for the purpose of showing the headles and treadles.Although… … Fig. 17. Figs. 16 and 17, are representations of tweels of four leaves, and asthe fabric of tweeled cloth is generally thick and close, they, beingon a large scale, will convey a clear idea of its appearance, as theyare designed to give an accurate representation of the intersectionsof the threads.…
