Gilroy, Clinton G · New York, G. D. Baldwin · leaf 477
440 THE ART OP WEAVING. exhausted in the shuttle, or when the taking up of the clothupon the cloth roUer is not equal to its production ; such motion be-ing governed by the ordinary beat or Vibration of the lay. Fig. 212, represents a front elevation of the improved power loom;Fig. 213, a side… … The framing of the loom is marked a, a, «, supporting the severalwarp rollers ö, ö, 6^, from whence the warp threads proceed throughthe headles c, c, also through the reed d, d, of the lay e, over thebreast beam /, to the cloth roller g, as usual. This loom is alsoprovided with an additional…
Weaving
