Gilroy, Clinton G · New York, G. D. Baldwin · leaf 592
FIGURED WEAVING. 513 cylinder of the Jacquard; E, (Figs. 241 and 243) a thick brass orcast-iron plate, füll the thickness of the length of the piinches, fixedclose to the cutting plate G, the cutting plate in its position, withthe form or stud plate H, closed down and the punches forced intothe…
Weaving
