The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 205
We would here remark, that in describing the drawings just al-luded to, the same letters of reference indicate similar parts in all ofthem. A A, Fig. 95, is the frame of the machine, connected bysuitable cross bars at BBBB; the two upright posts C C, one at 25 194 THE ART OF WEAVING. each end of… … are shown in Fig. 93: into these are inserted the pointed screwsF F, which are fastened by means of the thumb screws G G ; thesebeing brought against the cross pieces E E after the screw points JACQUARD MACHINE. 195 H H have been inserted into small brass or steel bushes on the sidesof the cylinder…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
