The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 217
re metallic rods, which pass through theboard C, and are screwed or otherwise secured to the board D : theends Q, Q, of these rods guide the board D, and keep it in its properplace. The under extremities of the slides E E are attached to theends of the lever or cross bar R, (which may also be seen… … caught in its descent by the hooks T T (see Fig. 99,) attached tothe frame of the loom at S S. W W are levers, which work in the slides E E, and arepressed by springs K K, in order to bring and keep the trunksquare (as is well understood, of course, being so like the ap-paratus used for a similar…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
