The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 368
arts delineated as we consider re-quisite to explain and show the position in which the improvementsare applied. In Fig. 157, A, represents the driving pulley keyed on thecrank shaft, which gives motion to the lay ; B, the yarn beam ;D, Fig. 158, the cloth roller; and C, the tappet shaft by… … supported at each side of the loom, parallel to, and immediatelyabove the yarn beam B: on this shaft is made fast two arms F, andF. The extremity of the arm F, carries a shaft G, similar to thatmarked E, and crossing the loom in the same way: the shaft E \* K 350 THE ART OF WEAVING. moves freely on…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
