Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)

Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 10

An illustration from Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed, 1911, leaf 10
. 58—Universal joint. 59—Exhaust pipe. 60—Brake rod. 61—Pressure feed pipe for gasolene. 62—Driving shaft. 63—Muffler. 04—Universal joint. 65—Rear side spring. 66—Bevel gear driving pinion. 67—Differential pinion stud. 68—Differential pinion. 09—Differential housing. 70—Main gasolene tank. 71—Rear…

Automobiles

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
