Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 136
^ V\^. 49.—The Schebler Carburetter. A compensating air valve A, adjust-iible by the screw M and the spring O, controls the air supply to the mixingchamber C. Above this valve is a shutter which may be partially closedwhen cranking to increase the suction in order to obtain a rich mixture. Thespray…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
