Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 194
the cycle arebriefly as follows: i, a primary current flows and magnetizes IGNITION 167 the core, 2, the magnetized core attracts the vibratorwhich breaks the primary circuit, 3, the core loses itsmagnetism and the vibrator springs back to its originalposition, and 4, the vibrator, by returning to… … Fig. 74.—A hammer vibrator. When at rest, the upward tension of thespring which carries the armature A, holds the platinum points in contactand causes the upper spring C, to leave the shoulder of adjusting screw Dand rest against the heavy brass plate above it. When the iron core, B,attracts the…
Automobiles
