Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 234
MAGNETO … SWITCHGROUND Fig. 120.—Wiring diagram for a six cylinder car, illustrating a double igni-tion system with two sets of spark plugs. One system consists of a high tensionmagneto with connections from its distributing terminals to one set of sparkplugs; a second system is composed of a battery,…
Automobiles
