Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 247
no lost motion,what must be done? Ans. One of the pistons, say, ^--1, in fig. 121 is put ontop center, a space amounting to about 5°-io° is then markedoff on the fly wheel rim, and the engine turned ahead imtilthis mark comes even with the center pointer; the gearsof the exhaust cam shaft are then… … C^AMAT SMA^r t/9fif^ft $H^/^r Figs. 131 and 132.—Diagrams showing rotation of cam shafts with adirect gear drive. Ques. When shifting the cam shaft to make the valves earlieror later, should it be turned respectively, with, or against the direc-tion of rotation of the crank shaft? Ans. That depends…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
