Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)

Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 8

An illustration from Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed, 1911, leaf 8
TL151.B71912X 3 9358 00143378 5 … 69 68 67 66 45 43 42 41 40 CROSS-SECTIONAL DIAGRAM OF A FOUR-CYLINDER TOURING CAR. 1—Divided front scat fi)r chauffem. 2—Throttle lever. 3—Steering wheel. 4—Steering pillar. 5—Brake or clutch lever. 6—Spark coil. 7—Spark coil vibrator. S—Gravity feed (ja-soleiu liink. 9—Water jacket…

Automobiles

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
