Augsburg, De Resco Leo, b. 1859 · Boston, New York, Educational Pub. Co · leaf 106
Find prominent points, such as the width of the top A E,the width of the bottom F G ; the height or width of the handleH ; the points where the handle joins the body as I and J, etc.These lesser points are tiken by the unaided eye. It is compara-tively easy to locate a point, if our attention is… … DRILL EXERCISES. Procure for a model several cylinders sawed from the limb ofa tree similar to Fig. 4(5, only not so large. If the cylinders con-tain a knot or other features, so much the better. If these modelscannot be procured, a round box such as a l>aking powder can willdo, but it is not so…
Drawing
