Augsburg, De Resco Leo, b. 1859 · Boston, New York, Educational Pub. Co · leaf 116
at the left of theeye with X removed. Fig. 15 represents the same in a vertical AUGSBURGS DRAWING. 113 position. Fio^. 16 represents the same in a horizontal position,and Fig. 17 in an oblique horizontal receding position. All of the figures, 6-13, may be drawn in any or all of thesepositions. 40.… … In drill icork if is Itetter to draw one object seven times tJian sevenobjects one time. Use for a model a strip of paper aliout one inch wide, rolledaround a lead pencil, as shown l>y models 18, 19 and 20. Fig. 18 is drawn on the principle of a receding cylinder, Fig.19 of a vertical cylinder,…
Drawing
