Augsburg, De Resco Leo, b. 1859 · Boston, New York, Educational Pub. Co · leaf 54
^rio Drill Exercises Based on Fig. 10. 16. Remove block 2 and place on 1, and block 3 and placeit under 4. 17. Remove block 1 and place it at the left of 3. 18. Remove block 1 one-half of a block to the rio;ht. AUGSBURGS DRAWING. 51 19. Remove block 2 one-half of a block to the left. 20. Remove… … Figs. 11 and 12 represent two very serviceable models thatmay be used to great advantage at this })oint. Fig. 11 is simply two blocks nailed together in the form of anL, and Fig. 12 is a smaller block nailed to a larger one so that onecorner and two sides are even. These models may l)e drawn in a…
Drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
