Augsburg, De Resco Leo, b. 1859 · Boston, New York, Educational Pub. Co · leaf 79
ved faces are always weak, haviiiir <iiiy one and never morethan two lines to indicate the curvature, hence they may be shaded. Note.— See the cliapter on Wash Drawing in Boole III. for fnll directions inshading. Fig. 4 is a box with the faces marked with letters. Drawthis box and remove the… … AUGSBURGS DRAWING. .77 5. Remove faces B, C and D. 6. Remove faces B and F. 7. Remove faces B and E. 8. Remove faces C and D. Four crayon boxes are Use for inodeJs four cubical blocks,excellent models for general use. Fig. 5 is a small cube. Add similar cubes to the faces asfollows : 9. Add to face…
Drawing
