Fig. 6 is a large cube composed of eight smaller ones. Addsimilar cubes to the small ones as follows : 16. Add cubes to faces 3, 6 and 10. 17. Add cubes to faces 1, 5 and 9. 18. Add cubes to faces 4, 13 and 14. 19. Add cubes to faces 2, 7 and 12. 78 AUGSBURGS DRAWING. … 20. Remove cube 1. 21. Remove cubes 3 and 6. 22. Remove cubes 4 and 5. Figs. 7 and 8 are two very serviceable models made by nail-ing or gluing two blocks together. Fig. 7 is L shaped. Fig. 8 ismade by placing a smaller block on a larger, so that one cornerand two sides are even. These blocks are…
