and Plugs.—A reproduction of a photograph of asingle position switchboard of this type with a capacity of about 60lines is given in Fig. 157. This type of board is commonly equippedwith regular cord circuits for interconnecting local lines and for connect-ing them to the trunks; and also with two… … 162 AUTOMATIC TELEPHONY the toll board or from the switches at the central office. This board hasthe customary supervisory and night-alarm circuits. A general diagrammatic scheme of the circuits is shown in Fig. 158.The line circuit is equipped with relay and lamp signals. The regularcord circuit…
