pieceit closes circuit through the outsidewinding of the meter from negativebattery to the private normal, which isof course connected to earth. At thesame time, however, circuit has beenclosed through the inside winding ofthe meter, which is connected in seriesin the negative side of the trunk to… … Fig. 175.- -Lineswitch unit with metersat top. stage of the connection these that the meter armature is not attracted. sponds, however, and his connector reverses the direction of the current flow in the calling partys loop then the inside meter winding assists the outside winding and the meter…
