Edwards, John Isaac, Wells, Reginald Ellis, author · leaf 38
andthe volume of the gases is reduced by cooling owing to tiiegreat cooling surface presented. The gases escape from aroundthe outer edges of these difcs in a thin strerun. This equal distribution of the escaping gases over a longand narrow area eliminates to a large extent the explosi^echaracter… … The Piercemuffler is alarge expansion -liamber, 5 5/8 X 30. This is divided into seventeen compartments bypierced sheet iron diaphragms. The separating diaphragms are oftv/o sorts, one perforated with 3 circles of 9/32 holes, theag-regate small hole area equaling that of the 2 diameteropenings with…
Automobiles · Theses
Internet Archive · University of Illinois Urbana-Champaign · Public Domain Mark 1.0. Free to use for anything.
