The blank skorvn in thecenter is the result of one operation on the press. 4—Cowl assembly shounny the blanks for the dash,colli top and sides. The left and riyht sides are stamped out toyether and then cut apart. 5—Jiy forputting in holt holes. The jig is curved to conform to the finished shape of… … —Roof of the Jewett sedan. It is a very co^nplete wood frame and acts as a part of the body structure.8—Final operation on the wood fra/tne. 9—The windshield is built into the front pillar and the visor isturned up at the forward end to act as a rain shed. 10—To keep the front pillar an >iarrow…
