Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 211
77. It iscompletely described in the instruction book issued bythe company from which the following extracts are repro-duced by permission. Crank-shaft, connecting rods andall other parts within the crank-case and cylinders arelubricated directly or indirectly by a force-feed oilingsystem. The… … <5 Cj ^ ^ too 212 Hall-Scott Lubricating System 213 from connecting rod bearing directly upon the wrist pin.The oil is drawn from the strainer located at the lowestportion of the lower crank-case, forced around the mainintake manifold oil jacket. From here it is circulatedto the main…
Airplanes
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
