Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 242
IS Note DecreasedSide ThrustBecause of LeaserAngle ofConnecting Rod … t Resistance to Motion Center Line ofCrank /] Center Line ofCylinder Fig. 91.—Diagrams Demonstrating Advantages of Offset Crank-Shaft Construction. in direction of the arrow there is a certain resistance tomotion which is proportional to the amount of energyexerted by the engine and the resistance…
