Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 491
r, but for emergency purposes as in seaplanes orfor a quick get away if landing inadvertently inenemy territory, a hand starting crank is provided. Thisis supported in bearings secured to the pressed steelcarriers of the engine and is provided with a universal 492 Aviation Engines joint between the… … Fig. 213.—G. V. GnomeMonosoupape,, with Cam-Case Cover Removed toShow Cams and Valve-Operating Plungers with Roller Cam Followers. with helical teeth of such hand that the starting pinionis thrown out of mesh as soon as the engine picks up itscycle. A coiled spring surrounds part of the shaft of…
Airplanes
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
