Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 502
e eccentricityof the centers of rotation the piston will reciprocate inthe cylinders. This distance is at its maximum whenthe cylinder is above 0 and at a minimum when it isabove M, and the difference between these two positionsis equal to the stroke, which is twice the distance of thecrank-throw… … Firing Order*1-3-5-1-9-2-4-6-8 Fig. 222.—Diagrams Showing Le Rhone Motor Action and Firing Order. the cylinders rotate around point 0 in the direction ofthe arrow. An odd number of cylinders acting on onecrank-pin is desirable to secure equally spaced explosions,as the basic action is the same as…
