io6 BENCH WORK IN WOOD. ened by using a mortise-gauge (33), which makes both lines atthe same time. 165. Cutting the Mortise. — It will be remembered that thelines which appear on face B, Fig. 190, have their counterparts … on the opposite face D. To cut the mortise, select a chiselhaving a width as nearly as possible equal to the space betweenthe gauge lines, and, beginning on face B, near the middle ofthe mortise, advance toward one end, as shown by Fig. 149.The end of the mortise having been reached, commence at…
