BENCH WORK. 109 may be located on the mortise and tenon by direct measure-ment ; or the cheeks of the mortise may be bored through and o4ee \ ^ mrm<> o r I 1. £ <—^--^ ^. ^. ^ CO r 3 ^ > z ^ t^ ^ … o ^ ^ the tenon inserted, and marked by putting the bit into the hole /^^ already bored and forcing its 5 point against the tenon. The ° tenon may then be withdrawn ^ and bored, the point of the bit being placed a little nearer the shoulder of the tenon than the mark. no BENCH WORK IN WOOD. The…
