Bench work in wood: a course of study and practice designed for the use of schools and colleges (1902)
Goss, W. F. M. (William Freeman Myrick), 1859-1928 · Boston, Ginn & company · leaf 16
-and-Tenon Joints.— 241. Single and Double Tenons. — 242.Haunching. — 243. Four Tenons. — 244. Mortises and Tenonsat an Angle in the Work. — 245. Modifications of Mortise-and-Tenon Joints , 148-152 Paneling. 246. Panel. — 247. Frame. — 248. Joints between Panel and Frame 152-155 FASTENINGS. 249.… … INTERPRETATION OF MECHANICAL DRATVINGS. I. Most of the illustrations presented with the followingchapters are in the form of Mechanical Drawings. To thenovice, these may appear confusing; but careful attention tosome of the principles underlying their con-struction will enable him readily to…
Woodwork (Manual training)
