FlG. 81 A LARGE FRAME PLANER AND ITS OLD CAST-IRON DRIVING GEAR THAT WAS NOT STRONG ENOUGH TO WITHSTAND THE HEAVY CUTS TAKEN WITHHIGH-SPEED TOOLS. ON THE RIGHT IS THE MECHANIC WHO PUSHED THIS MACHINEUP TO THE LIMIT, AND THE LEFT THE PROGRESSIVE FOREMAN WHO HAS DONE MUCHIN AN ENERGETIC WAY TO… … FIG. 82—THE OLD AND NEW DRIVING GEARS FOR FRAME PLANER. THE ONEON THE LEFT IS THE ORIGINAL GEAR OF CAST-IRON. THE FAILURE OF THIS GEARUNDER THE HEAVY DUTY IMPOSED EY HIGH-SPEED TOOLS IS SHOWN IN THE LARGENUMBER OF BROKEN TEETH. THE NEW STEEL-RIMMED GEAR SUBSTITUTED FORTHE OLD ONE, IS SHOWN ON THE…
