Bicknell's village builder. Elevations and plans for cottages, villas, suburban residences, farm houses [etc.] also exterior and interior details for public and private buildings, with approved forms of contracts and specifications. Containing fifty-five plates drawn to scale (1872)
Bicknell, A. J. (Amos Jackson) · New York, A.J. Bicknell & Co. · leaf 90
s ; c c c c, wash troughs • d d, wastesoil pipes; e e e e, dining-room closets; f f, flues of range and furnace ;g g, hot air flues; h h, hot air registers or grates; i i i i, ventilating ducts ;k k k k, chamber closets; k, hall closets; k k, closet under stairs; 11, water-closets in basement; 111,… … O^^*^^ ^. ^ .X
Architecture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
![An illustration from Bicknell's village builder. Elevations and plans for cottages, villas, suburban residences, farm houses [etc.] also exterior and interior details for public and private buildings, with approved forms of contracts and specifications. Containing fifty-five plates drawn to scale, 1872, leaf 90](https://img.insideoutlibrary.com/img/1024/ia-bicknellsvillage00bick-90-71.webp)
