versatec :: 5990-01 C2700 Series Thermal Transfer Color Plotter Operator Guide Oct1986 (1919)
leaf 32
Figure 2-4. Unpacking the Media Cassette C2700 SERIES THERMAL PLOTTER OPERATOR GUIDE 2-3 INSTALLATION 11. Close the plotter cover securely. 12. Slide out the foam cushion from beneath the media sensor lever,located inside the media cassette slot at the top of the plotter asshown in Figure 2-5.… … MEDIA SENSOR LEVER FOAM CUSHION Figure 2-5. Freeing the Media Sensor Lever 13. Slowly pull the paper sheet and foam strip through the ejectrollers at the top of the plotter (Figure 2-5). C c INSPECTION Once the C2700 plotter is unpacked, carefully inspect the plotter andaccessory kit for possible…
