ing Instructions,and perform the operational checkout. C2700 SERIES THERMAL PLOTTER OPERATOR GUIDE 3-9 LOADING THE INK DONOR ROLL AND MEDIA LOADING MEDIA (TRANSPARENCY FILM) 1. Prepare the media cassette with the lever (Figure 3-11). < 1 11111 H WSmim * •* LEVER Figure 3-11. Media Cassette 2.… … Figure 3-12. Inserting the media cassette c 3-10 LOADING THE INK DONOR ROLL AND MEDIA 4. Before loading transparency film, remove the protectivetissue from each sheet. 5. Lift up the lever of the media cassette and a metal plate in thepaper cassette goes down. Refer to Figure 3-13.
