Position 6. Drawing Very Large Circle with Spread Compass and Lengthening Bar 90 MECHANICAL DRAWING 25 … Position 7. Adjusting Dividers with One Hand. between Legs Note Second and Third Fingers DONTS IN DRAFTING WORK Dont fold a drawing. Dont stick the dividers into the drawing board. Dont use the dividers as picks. Dont use the scale to rule lines. Doiit fail to clean the table, board, and…
