Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 205

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 205 — adius of11 or If inches, describe short arcs intersecting at I. A line 0 D.drawn through the points 0 and I, bisects the angle. In solving this problem the arc E F should not be too near thevertex if accuracy is desired. Proof. The central angles A 0 D and DOC are equal be-cause the arc E F is… … ^ ^ ^ U4

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
