Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 208

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 208 — om the sides. Problem 15. To inscribe a regular pentagon in a given circle. With 0 as a center and a radius of about 1^ inches, describethe given circle. With the T-square and triangles draw the centerlines A C and E F perpendicular to each other and passing throughO. Bisect one of the radii, 0 C,… … S5I 4:

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
