An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 211 — d a radiusequal to one-half the major axis, describe a circie. Similarly withthe same center and a radius equal to one-half the minor axis, describeanother circle. Draw any radii such as 0 C, 0 D, 0 E, 0 F, etc.,cutting both circumferences. These radii may be drawn with the60 and 45 degree… … c 5_ 1 - -I
