Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 211

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 211 — Vjttc^^^^^: … I I 132 MECHANICAL DRAWING 67 the small circle, draw horizontal lines The intersections of theselines are points on the ellipse. Draw a free-hand curve* passing through these points; aboutfive points in each quadrant will he sufficient. Problem 21. To draw an ellipse by means of a trammel. As in…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
