Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 269

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 269 — Fig 176. Oblique View ofCube at 60 Degrees Fig. 177. Oblique View of Hollow Cylinder inclined piece and the front edge of the bottom piece. Fig. 181.From this point draw a dotted line parallel to the length. Thehorizontal distances from the upper left corner to the dotted perpen-dicular are then…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
