Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 285

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 285 — Fig. 204. Plan, Elevation, and Deveropment of a Square Pyramid and Cutting Plane The prism and its development are shown in Fig. 203. Theprism is 3 inches high, and the base is inscribed in a circle 2| inchesin diameter. The plane forming the truncated prism is passed asindicated, the distance AB…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
