Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 275

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 275 — TrU^GBJ^T OR DIRECTOR ■ imetrical Constructions for Cycloid and Hypocycloid If the generating circle has a diameter equal to the radiusof the director circle the hypocycloid becomes a straight line. ■i/cloid. If the generating circle rolls upon the outside of the director circle, the curve…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
