Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 305

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 305 — nts ahexagonal bar. In this case, center lines shouldbe drawn. The front elevation A, shows thelength of the bar, and the plan B, shows the formand the distance between faces. The vertical linesin the front elevation show the corners of thehexagonal form while both views show the dis-tance from… … /: Projectionvigonul Xut

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
