Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 115
Fig. 42 A. An Alcohol Burner of this kind with little trouble and at a smallcost. Cut out of sheet iron a plate Vis inchthick and 7 inches in diameter and turn up the … Fig. 42 B. A Bunsen Flame Stove edges Vs inch all the way round to form a pan;rivet three legs to it so that it can be set underthe boiler with the plate at about the height of 1 L. E. Knott Apparatus Co., Boston, Mass. Making Small Boilers 101 the grate and tilting toward the back a little asshown…
Steam-engines
