Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 18
metal ball ana he fitted two short bent pipes intoholes on the opposite sides of it. Next hemounted the ball on a pair of hollow pipes, ortrunnions as they are called, so that it would re-volve easily and the lower ends of these pipes The First Engines 3 were fixed to a boiler, all of which is… … Fig. 1. Heros Reaction Engine or Eolipile it acted much the same as a rubber ball does whenit strikes a sidewalk, that is it reacted on the hol-low ball forcing it to turn in the opposite di-rection and at a fairly high speed, like unto thewinds let loose by the god Eolus. This is thereason an…
Steam-engines
