Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 192
to the back tube sheet withit. Also paint the cab, the wheels, the head-lightand the pilot with it to make them a shiny black.The steam dome, sand box, smokestack, smoke-box and that part of the furnace which showsbelow the cab should be painted a dull black andthis can be done by simply adding… … 178 The Boys Book of Engine-Building steam rises to the highest point which is thesteam dome; from the dome it passes throughthe throttle stand pipe, as the bent up end of themain steam pipe is called, the amount goingthrough depending on the steam pressure andthe distance the throttle valve is…
Steam-engines
