^45? … QtmMT THROAT Fig. 20. Construction of the Turbine Nozzle haust steam can be piped away from it. A metalcase or housing as it is called, can be made bycutting out two metal plates Vw or % inch thickand 4% inches wide and high and rounding theupper halves as shown at A in the side view,Fig. 21. Clamp…
